Third generation SL (2010–2016) / Kia Sportage SL Service & Repair Manual / Engine Mechanical System / Intake And Exhaust System / Intake Manifold: Repair procedures
Third generation SL (2010–2016) / Kia Sportage SL Service & Repair Manual / Engine Mechanical System / Intake And Exhaust System / Intake Manifold: Repair procedures. Removal and Installation: 1. 1994 - 2010 Kia Sephia, Spectra and Sportage Haynes Repair Manual Covers Repair of 1994 - 2010 Kia Sephia, Spectra and Sportage by Haynes. Kia service manuals are readily downloadable from this site for no cost. When you think of the saving that a good service manual can represent for you as a driver, this is worth bearing in mind – just print it out and keep it anywhere you might need it – it may enable you to make the repairs yourself. Spectra LX 2009 - Kia - Sportage.
| 2. | Disconnect the battery negative terminal (A). 4.0 ~ 6.0N.m (0.4 ~ 0.6kgf.m, 3.0 ~ 4.4lb-ft) |
|
| 3. | | (1) | Remove the air duct (A). |
| (2) | Disconnect the breather hose (B), the recirculation hose (C) and brake booster vacuum hose (D). |
| (3) | Disconnect the air intake hose (E) and then remove the air cleaner assembly (F). Hose clamp bolt: Air cleaner assembly bolts: |
|
|
| 4. | Disconnect the recirculation valve connector (A) and the vacuum hose (B), and then remove the intercooner inlet pipe & hose assembly (C). Hose clamp bolt : Pipe mounting bolt: 14.7 ~ 19.6 N.m (1.5 ~ 2.0 kgf.m, 10.8 ~ 14.5 lb-ft) |
|
| 5. | Disconnect the boost pressure sensor connector (A) and then remove the intercooler outlet pipe & hose assembly (B). 4.9 ~ 6.9 N.m (0.5 ~ 0.7 kgf.m, 3.6 ~ 5.1 lb-ft) |
|
| 7. | Loosen the drain plug, and drain the engine coolant. Remove the radiator cap to drain with speed. (Refer to Cooling system in this group) |
| 8. | Disconnect the PCV hose (A), the intake OCV (Oil control valve) connector (B) and the OTS (Oil temperature sensor) connector (C). |
| 9. | Disconnect the A/C compressor switch connector (A), the alternator connector (B), the OPS (Oil pressure switch) connector & injector extension connector (C), the knock sensor connector (D), the MAPS (Manifold absolute pressure sensor) & IATS (Intake air temperature sensor) connector (E), the ETC (Electronic throttle control) connector (F) and the vacuum pump connector (G). |
| 11. | Remove the oil level gauge (A). |
| 13. | Remove the intake manifold (A) after disconnecting the vacuum hoses. 18.6 ~ 23.5N.m (1.9 ~ 2.4kgf.m, 13.7 ~ 17.4lb-ft) |
When installing the intake manifold, tighten the bolts and nuts with pre-torque first, and then tighten the bolts and nuts with specified torque in the sequence shown. |
Intake Manifold: Components and Components Location
Components 1. Intake manifold assembly 2. Electronic throttle body3. Intake manifold stay4. Intake manifold gasket .. Exhaust Manifold: Components and Components Location
Components 1. Hear protector2. EWGA(Electric Waste Gate Actuator)3. C-ring4. Turbo manifold module5. Turbocharger stay6. Trubo adapter gasket7. Turbo adapter8. Turbo adapter heat protector9. Oil .. Other Information:
